Standards

IEEE 802.3: 10Base-T

IEEE 802.3u: 100Base-Tx/100Base-Fx

IEEE 802.3z: 1000Base-X

IEEE 802.3ad: 1000Base-Tx

Port

RJ45

8*10/100/1000Base-T

SFP

2*1000Base-FX SFP

Switch properties

Backplane bandwidth

20Gbps

Exchange delay

7μS

Priority queue

4

MAC table size

1K

Packet buffer size

512K

Device management

Indicator lights

Power1、Power2

Power

Input voltage range

Dual DC input，12 to 60VDC，5-pin

Power consumption

＜10W

Overload current protection

Supported

Reverse polarity protection

Supported

Environment

Storage temperature

-40 to +85℃

Operating temperature

-40 to +75℃

Operating humidity

5% to 95% no-condensing

Physical specification

Housing

Metal

Ingress protection rating

IP40

Dimensions(W x D x H)

68 x 105 x 146mm

Weight

0.9KG

Mounting options

DIN rail mounting or wall mounting

Amber200-8FX2GX

DIN rail type unmanaged 10-ports industrial Ethernet switch, eight 100M SFP, two 1G SFP

Amber200-8GE

DIN rail type unmanaged 10-ports industrial Ethernet switch, eight 10/100/1000M Base T

Amber200-8FE

DIN rail type unmanaged 10-ports industrial Ethernet switch, eight 10/100M Base T

Amber200-8FE1FX

DIN rail type unmanaged 10-ports industrial Ethernet switch, eight 10/100/1000M Base T, one 100M SFP

Amber200-8FE1GX

DIN rail type unmanaged 10-ports industrial Ethernet switch, eight  10/100M Base T, one 1G SFP

Amber200-8FE2FX

DIN rail type unmanaged 10-ports 1industrial Ethernet switch, eight 10/100M Base T, two 100M SFP

Amber200-8FE2GX

DIN rail type unmanaged 10-ports industrial Ethernet switch, eight 10/100M Base T, two 1G SFP

Amber200-8GE1GX

DIN rail type unmanaged 10-ports industrial Ethernet switch, eight 10/100/1000M Base T, one 1G SFP

Amber200-8FE4FX

DIN rail type unmanaged 10-ports 1industrial Ethernet switch, eight 10/100M Base T, four 100M SFP
